Details
THE PERFECT BLEND
The Polygon Strattos strikes the perfect balance between endurance comfort and race-inspired performance. Its geometry offers an upright position that reduces strain on long rides, yet remains aggressive enough for a powerful and efficient ride. Thanks to the carbon frame, the Strattos S7X weighs a respectable 9.11kg—perfect for crushing gran fondos or clocking up weekend miles.
EFFICIENCY AND SPEED
Building on the classic lines and styling of a race bike, the lightweight carbon frame features subtle aerodynamic cues on the tubing and internal cable routing to reduce wind resistance. Meanwhile, the stiff downtube, thru-axles, and wide bottom bracket ensure an efficient platform for power transfer to put down some watts!
ENDURING COMFORT
Don’t sacrifice comfort for speed. The Strattos features flex stays, dropped seat stays, and a seatpost with an internal wedge to absorb road vibrations, keeping you comfortable on long rides. The full carbon fork and steerer also reduce weight in the front end for improved comfort while maintaining precise handling.
A TRUSTED BRAND
Polygon has over 30 years of experience creating high-performance bikes at competitive prices. Polygon road bikes have led to numerous national titles and even a victory at the 2023 Tour de Taiwan. With a 5-year warranty, you can trust Polygon to deliver from the factory to the track.
Specs
| frameset | |
|---|---|
| Frame | ACX All-Round Uci Approved, Internally Routed, Pressfit BB86, 12x142mm |
| suspension | |
| Fork | Full Carbon, Taper 1-1/8" To 1-1/2", Flat Mount Disc Brake |
| drivetrain | |
| Rear derailleur | Shimano 105 Di2 RD-R7150 Direct Attach |
| Front derailleur | Shimano 105 Di2 FD-R7150 Braze-On |
| Shifter | Shimano 105 Di2 ST-R7170, 2x12-Speed Dual Control Lever |
| Crank | Shimano 105 FC-R7100 |
| Chainring | 50/34T |
| Cassette | Shimano 105 CS-R7101, 11-34T |
| Chain | KMC X-12 |
| brakes | |
| Front brake | Shimano 105 BR-R7120 Hydraulic Disc, 160mm SM-RT70 Rotor, Center Lock |
| Rear brake | Shimano 105 BR-R7100 Hydraulic Disc, 140mm SM-RT70 Rotor, Center Lock |
| wheels | |
| Front hub | Novatec D791SB-CL, 12x100mm |
| Rear hub | Novatec D792SB-CL-X12, 12x142mm |
| Rim | Entity Alloy Double Wall, 30mm Depth, 19mm Inner, 24H, Tubeless Ready |
| Tyre | Schwalbe One, Addix, Raceguard, Microskin, 700x28C, Tubeless ready |
| contact points | |
| Handlebar | Entity Xpert Alloy, 31.8mm, 125mm Drop, 70mm Reach |
| Saddle | Entity Flux2, Cr-Mo Ø 7mm |
| Seatpost | Entity Xpert Alloy, 27.2 x 350mm, 15mm, Integrated Shape W/ Bolt |
| Stem | Entity Xpert Alloy, 31.8mm, 10° |
| weight | |
| Bike weight | 20lbs (Size M) |
Geo
| XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Rider's height in cm | 5'1" – 5'5" | 5'4" – 5'7" | 5'6" – 5'9" | 5'8" – 6'0" | 5'11" – 6'2" | 6'1" – 6'5" |
| (A)Stack | 495 | 511 | 534 | 558 | 584 | 612 |
| (B) Reach | 383 | 384 | 387 | 390 | 392 | 403 |
| (C) Head Tube Angle | 72 | 72.5 | 73 | 73 | 73 | 73 |
| (D) Head Tube Length | 90 | 105 | 130 | 155 | 185 | 215 |
| (E) Seat Tube Angle | 75 | 74.5 | 74 | 73.5 | 73 | 73 |
| (F) Seat Tube Length | 454 | 474 | 500 | 525 | 554 | 584 |
| (G) Top Tube Effective | 515 | 525 | 540 | 555 | 570 | 590 |
| (H) Bottom Bracket Height | 271.5 | 271.5 | 274 | 274 | 277 | 277 |
| (I) Bottom Bracket Offset | 72.5 | 72.5 | 70 | 70 | 67.5 | 67.5 |
| (J) Chainstay | 415 | 415 | 415 | 415 | 417 | 417 |
| (K) Wheel Base | 976 | 977 | 985 | 995 | 1008 | 1028 |
| (L) Standover Height | 729 | 749 | 776 | 801 | 832 | 862 |
| Handlebar Width | 400 | 400 | 400 | 420 | 420 | 420 |
| Stem Length | 90 | 90 | 100 | 100 | 110 | 110 |
| Crank Length | 165 | 170 | 170 | 170 | 172.5 | 172.5 |
Build
Strattos S7X - Assembly Guide
Your bike needs minor assembly before riding; use the tools and videos included.
As a guide, it'll take 10-40min depending on whether you're an experienced bike assembler or have little to no mechanical experience.
Side Note: Your cables will stretch during the initial bed-in period and must be adjusted by an experienced mechanic around 150km of riding.
How To Unbox Your Strattos
Dial In Your Bike Fit
Dial In Your Tyre Pressures
