Details
DIALLED FOR AIRTIME
Whether you're hitting the local dirt jumps or sessioning the skatepark, the Trid is built to elevate your riding. The lightweight aluminum frame and responsive geometry make it easy to throw down tricks with style, while the air-sprung X-Fusion Slant DJ fork with 100mm of travel ensures smooth landings.
ENGINEERED FOR PROGRESSION
The Trid is equipped with reliable components that can handle the abuse of dirt jumping. The Shimano MT201 hydraulic disc brakes provide powerful stopping power, while the Vee Tire Co. Speedster tare fast rolling with enough grip to rail berms. The single-speed drivetrain keeps things simple and reliable, allowing you to focus on your tricks.
30 YEARS OF EXPERIENCE
Polygon is a factory-direct brand with over 30 years of experience crafting high-performance bikes at competitive prices. Vertically integrated manufacturing ensures quality and cost savings. Their mountain bikes have been tested on the world stage at events like Redbull Rampage and the World Cup circuit, boasting a 5-year frame warranty for peace of mind.
Specs
| frameset | |
|---|---|
| Frame | AL6 Dirt Jump, 135mm O.L.D., 100mm Travel, Is Mount 160mm, Horizontal Dropouts |
| Headset | Internal Sealed Bearing, ZS 44/28.6 | ZS 56/40 |
| suspension | |
| Fork | X-Fusion Slant DJ 26" Air, Rebound & Compression Adjuster, Tapered, 15x100 Thru-Axle |
| drivetrain | |
| Crank | Samox TAF15-D32A 32T, 170mm |
| Cassette | Cog 2.3x14T |
| Chain | KMC HL-1 Half Link, Single Speed |
| brakes | |
| Front brake | Shimano BR-Mt201 Hydraulic Disc, Rotor F: 180mm R: 160mm |
| Rear brake | Shimano BR-Mt201 Hydraulic Disc, Rotor F: 180mm R: 160mm |
| wheels | |
| Front hub | Alloy Double Wall Rim & Hub, Thru Axle & Track Nut Hub, 25mm Inner Width, 15 Engagement Points |
| Rear hub | Alloy Double Wall Rim & Hub, Thru Axle & Track Nut Hub, 25mm Inner Width, 15 Engagement Points |
| Tyre | VeeTire Speedster (Two Six DJ), 26x2.25", Skin Wall |
| contact points | |
| Handlebar | Polygon Alloy, 750mm |
| Saddle | Polygon Pivotal Saddle |
| Seatpost | Alloy, Pivotal, 30.9x200mm |
| Stem | Polygon Alloy, 40mm |
| Pedals | Nylon Flat Platform |
| weight | |
| Bike weight | 12.8 kg (28.22 lbs) |
Geo
| One Size | |
| Recommended Rider Height | 5'7" to 6'1" |
| (A) Stack | 584 |
| (B) Reach | 416 |
| (C) Head Tube Angle | 70° |
| (D) Head Tube Length | 120 |
| (E) Seat Tube Angle | 72° |
| Seat Tube Angle Effective | 72° |
| (F) Seat Tube Length | 30 |
| (G) Top Tube Effective | 600 |
| (H) Bottom Bracket Height | 327 |
| (I) Bottom Bracket Offset | 12 |
| (J) Chainstay | 385 |
| (K) Wheel Base | 1047 |
| (L) Standover Height | 651 |
* All lengths in mm
